Baumalight S22 Stump Grinder With 12V Swing Actuator For Skid Steers - BML-S22-S450-AUX

Baumalight S22 Stump Grinder with 12V Swing for Skid Steers - BML-S22-S450-AUX

S450 Gerotor Motor (12 - 20 GPM) / Machine Joystick Control (Aux Connection)
$4,064.99
Sale price  $4,064.99 Regular price  $5,419.99
Skip to product information
Baumalight S22 Stump Grinder With 12V Swing Actuator For Skid Steers - BML-S22-S450-AUX
👑 Offre exclusive : -15% uniquement cette semaine avec le code PRIVILEGE
(offre valable jusqu'à dimanche 23h59)

Baumalight S22 Stump Grinder with 12V Swing for Skid Steers - BML-S22-S450-AUX

$4,064.99
Sale price  $4,064.99 Regular price  $5,419.99
In stock
lokicam shipping

Expédition sous 72h

loki garantie

Garantie 90 jours

4,7/5 sur 4300+ avis

⚡ Commandez avant 00h 00m 00s .
Payment methods
    Livraison et retours
    • Traitement et expédition : 1 à 3 jours après validation de votre commande
    • Livraison en France métropolitaine : 6 à 9 jours. Lien vers la politique
    • Retours : vous disposez de 30 jours après réception pour nous retourner vos articles. Lien vers la politique

    Baumalight S22 Stump Grinder With 12V Swing Actuator For Skid Steers - BML-S22-S450-AUX

    This innovative model uses a 12V electric linear actuator for enhanced torque and efficient grinding, bypassing traditional hydraulic systems. The S22 boasts three-sided carbide teeth that project 1-¼ inches for optimal clearance. Durability is guaranteed with hardened steel bushings and greaseable pins, designed to resist corrosion and ensure smooth operation.

    Baumalight S22 Stump Grinder

    Harness the power of the Baumalight S22 Skid Steer Stump Grinder, a premier tool in stump removal technology, designed specifically for full-sized Skid Steers. This robust grinder features a 12V electric linear actuator, enhancing the machine's efficiency by allowing you to swing the grinder while still channeling all hydraulic flow and pressure directly to the motor. This innovative design drastically speeds up the grinding process, ensuring swift and effective stump removal.

    The S22 is built to last with hardened steel bushings and greaseable pins, expertly crafted to resist corrosion and maintain smooth joint operation throughout its lifespan. Additionally, the stump grinder provides exceptional clearance with carbide teeth that extend 1-¼ inches from the rotor, promoting efficient debris removal and reducing rotor heat buildup for extended durability. Every S22 comes with a set of six replacement teeth, making maintenance straightforward and cost-effective.


    Specifications
    Model No. S14 S16 S18 S22 S24 S28 S40
    Recommended HP Size Mini Skidsteer Mini Skidsteer 25-80 25-65 30-80 50-120 50-120
    Maximum Carrier Size Check GPM & PSI Check GPM & PSI Check GPM & PSI Check GPM & PSI Check GPM & PSI Check GPM & PSI Check GPM & PSI
    Motor Type Gerotor Bent Axis Piston Gerotor Gerotor Gerotor Gerotor Bent Axis Piston
    Hydraulic GPM Check Stump Cutting Size Chart Check Stump Cutting Size Chart Check Stump Cutting Size Chart Check Stump Cutting Size Chart Check Stump Cutting Size Chart Check Stump Cutting Size Chart Check Stump Cutting Size Chart
    Rotor Size 18" 18" 24" 24" 24" 24" 24"
    Number of Teeth 12 24 34 34 34 34 20
    Tooth Part number H3000 H3000 S1000 S1000 S1000 S1000 H3000
    Tooth Construction High speed High speed Planer Planer Planer Planer High speed
    Cutting Wheel Speed Depends on GPM Depends on GPM Depends on GPM Depends on GPM Depends on GPM Depends on GPM Depends on GPM
    Cutting Height - Above Ground No limit No limit No limit No limit No limit No limit No limit
    Cutting Depth - Below Ground 6" 6" 10" 10" 10" 10" 24"
    Maximum Cutting Depth - Per Pass 2" 2" 5" 6" 6" 6" 1"
    Maximum Horizontal Cut 12" 12" 22" 22" 22" 22" 22"
    Swing Arc Self-feeding 56° Self-feeding 60° 60° 63° 85°
    Hub Torque 150 Ft.-Lbs. - 250 Ft.-Lbs. 250 Ft.-Lbs. 250 Ft.-Lbs. 803 Ft.-Lbs. -
    Over Torque Protection Relieve valve Relieve valve Relieve valve Relieve valve Relieve valve Relieve valve Remote
    Hitch 1" pivot pins 1" pivot pins Mini Plate Quick Attach Quick Attach Quick Attach Quick Attach
    No. of Remotes Required - Hydraulic 1 1 1 1 1 1 1
    Requires 12 Volt DC No Yes No Yes Yes Yes Yes
    Unit Weight (Shipping) Lbs. 394 400 642 - 995 995 1,200
